My terminal recording tool of choice is asciinema. It has a number of advantages:

  • Easy to use, scriptable
  • You can let it run in a terminal and not worry about pop-ups and such being recorded
  • Captures as text
  • Text can be extracted and used in other tools
  • Replayable to the terminal, optionally with different rows and columns
  • The agg command will convert to an animated GIF and compress wait time

asciinema

The asciinema --help and web site has full documentation, I’ll describe the commands I use the most.

Recording:

asciinema rec terminal.cast

This command will convert to a text file to read like a log.

asciinema convert --output-format txt terminal.cast terminal.txt

agg: asciinema to GIF

The agg tool converts a cast to an animated GIF. It can compress wait time, which I always use. The following command compresses wait time to 2 seconds.

agg --idle-time-limit 2 terminal.cast terminal.gif

Converting to MP4

Animated GIFs work and are fairly space efficient. However, recordings are typically in video formats. I experimented with ffmpeg to find the best configuration to convert to MP4. MP4 isn’t required, but it is commonly supported.

The ffmpeg command I’ve landed on:

ffmpeg -i terminal.gif -ignore_loop 0 -movflags +faststart -pix_fmt yuv420p -vf "scale=trunc(iw/2)*2:trunc(ih/2)*2" -c:v libx265 -crf 28 -preset veryslow terminal.mp4

Options:

  • -ignore_loop 0: ignore GIF loop
  • -movflags +faststart: streamable MP4 (plays before fully downloaded)
  • -pix_fmt yuv420p: maximize compatibility with players/devices
  • -vf "scale=trunc(iw/2)*2:trunc(ih/2)*2": ensures even dimensions
  • -c:v libx265: encode with H.265/HEVC
  • -crf 28: quality (lower = better); 18–28 typical (23 default)
  • -preset veryslow: speed vs compression (ultrafast → veryslow)

The -crf option is a tradeoff between quality and size. Terminal recordings do not need as much data, so 28 is a good value. I’ve found my MP4 files are smaller than the GIF using -crf 28. If the quality isn’t what you want, try 23.

Example

Animated GIF

asciinema terminal recording

Video

Size Comparisons

For a larger recording, I did some experiments to see what the file size would be. Quality is looks the same to me in all of these. I included the H.264 codec because it is older and more widely supported, but it isn’t as efficient.

Codec CRF Preset Size
GIF     19 MB
H.264 18 medium 38 MB
H.264 23 veryslow 24 MB
H.264 28 veryslow 18 MB
H.265 23 veryslow 15 MB
H.265 28 veryslow 11 MB

The importance of using a video file is compatibility and user experience. Not all applications will display the animated GIF properly. An animated GIF doesn’t give the user control to pause or navigate through the video.

If you only want to show your recording on a web browser, GIF can be a good option. If you want to distribute the file otherwise or let the user navigate, I recommend converting to MP4.
